Safety: the cabinet is equipped with a full range of sealed distribution boxes, each intelligent module and device is equipped with an independent control switch, and the cabinet is equipped with an advanced fire extinguishing device.
Attribute View: Support to view the current power information, temperature, SN code, cycle count, factory date and other information of all batteries.
High Compatibility: Support to store of different types of drone smart battery charging modules. Such as Phantom 4 charging module, M210 charging module, M300 charging module, Mavic 2 charging module, M600 charging module tablet charging module, wB37 charging module, and remote control charging module.
Over-temperature protection: The charging tank can automatically disconnect from charging when its own heat dissipation is poor or the ambient temperature is too high.
| name | Parameter type | parameter |
| industrial control | Industrial Control Panel Screen | 10.1inch |
| Resolution of the industrial control | 1280x800 | |
| Storage capacity of industrial computer | RAM：4GB；Storage：32GB | |
| Charging cabinet | Cabinet size (L*W*H) | 600*640*1175mm |
| Housing Material | Sheet metal thickness≥1.0mm | |
| lock | mechanical lock | |
| Cabinet cooling method | natural ventilation | |
| Access Voltage | 220V 50-60Hz | |
| Maximum simultaneous charging module support | 3 | |
| power distribution module | power distribution module | Distribution module must be encapsulated, do not allow the presence of bare wires, open, each power supply must be set up independently of the open and socket. |
| Physical isolation of the distribution module from the charging module | equipped | |
| charging unit | Charging unit data control | Adopt self-developed control motherboard and power charging module, do not allow the use of other equipment dismantled parts |
| Applicable models of batteries | DJI PHANTOM4、DJI Mavic2、DJI Mavic3、DJI M30/M30T、DJI M300、DJI M350、WB37 etc. series of batteries | |
| Tablet, remote control charging | With self-developed control chip, it can display the status of in position, out of position, charging, etc. | |
| communication module | All equipment inside the cabinet communication using wired connection, do not allow the use of WIFI and other wireless communication methods | |
| Fire protection | Fire protection | Soluble automatic fire extinguishing device |
| Test Reports | Explosion-proof rating | ≥T3 |
| Dust protection rating | ≥6级 | |
| waterproof rating | ≥5级 | |
| Fire Resistance Rating | ≥T3 | |
| Interface Requirement | interface protocol | Data interface protocols can be provided, including but not limited to battery status, battery information, etc. |
